Product Details
＋
The Nuage Networks 7850 Network Services Gateway (7850 NSG-C) is optimized for compact branch networking to drive the connectivity required by today’s cloud IT environments. The 7850 NSG-C is used to connect small branch locations to the enterprise SD-WAN with optimal network efficiency and centralized configuration management from the Nuage Networks Virtualized Services Platform (VSP). The solution offers multiple service scenarios, namely Layer 2 VPN, Layer 3 VPN, and internet breakout.
Specifications:
- CPU Intel E3825 (2 cores, 1.3 GHz)
- Memory 2GB
- Storage 16GB
- Interfaces
- ■3 x 10/100/1000BASE-T Gigabit Ethernet (RJ45)
- ■ 1 x USB 2.0 Standard-A female
- ■ 1 x USB 3.0 Standard-A female
- ■ 1 x RS-232 RJ-45 console
- Dimensions 124.26 mm x 19.4 mm x 119.66 mm/4.8 in. x 0.76 in. x 4.7 in. (width x depth x height)
- Weight 0.5 kg/1.1 lb
- Operating temperature 0° to 40° C / 32° to 104° F
- Operating relative humidity 5% to 90% at 40° C
- Power
- ■ Draw: 36 W (maximum)
- ■ Input: 100 to 240 V at 50-60 Hz, full range
- ■ Connector: C5
- Cooling Passive cooling
- Crypto-Acceleration CPU integrated Intel® QuickAssist
- Compliance agency certifications Safety:
- ■ EN 60950-1 2nd Ed CE-Mark
- ■ IEC 60950-1 2nd Ed CB Scheme
- ■ CSA/UL 60950-1 2nd Ed NRTL
- EMC:
- ■ ICES-003 Class B
- ■ FCC Part 15 Class B
- ■ EN 55032 Class B
- ■ CISPR 32 Class B
- ■ AS/NZS CISPR 32 Class B
- ■ VCCI Class B
- ■ KCC Korea-Emissions & Immunity (in accordance KN32/35)
- ■ IEC/EN 61000-3-2 Power Line Harmonics
- ■ IEC/EN 61000-3-3 Voltage Fluctuations and Flicker
- ■ EN 55024
- ■ IEC/EN 61000-4-2 ESD
- ■ IEC/EN 61000-4-3 Radiated Immunity
- ■ IEC/EN 61000-4-4 EFT
- ■ IEC/EN 61000-4-5 Surge
- ■ IEC/EN 61000-4-6 Conducted Immunity
- ■ IEC/EN 61000-4-8 Magnetic
- ■ IEC/EN 61000-4-11 Voltage Interruptions
- ■ EN 55011 Class B
- ■ EN 55022 Class B
- Security Built-in Trusted Platform Module to ensure integrity of system, operating system, and confidentiality of management and data-plane encryption
- Installation Desktop installation
