Model |
Husky IVO 150D |
|
Video performance (based on video stream 1080p, 30fps, 5-8 Mbit/s/channel, recording with VMD enabled), Throughput and channel count are measured separately, not in combination. |
|
|
Throughput (up to) |
150 Mbit/s |
|
Channel count (up to) |
20 |
|
Local storage (max) |
16 TB |
|
Hardware information |
|
|
Form Factor |
Desktop Small Form Factor (SFF) |
|
CPU |
Intel® Pentium® Gold G5400 |
|
GPU |
Integrated Intel® UHD Graphics 610 (Intel® Quick Sync Video) |
|
RAM |
8GB DDR4 |
|
Operating system (OS) |
Windows 10 IoT Enterprise SAC |
|
VMS/OS Storage |
256GB (M.2 PCIe NVMe) |
|
Number of hard drives |
1 x 3.5” (internal) |
|
Raw storage (gross) |
2/4/8/12/16 TB (Dell Enterprise Grade 24/7 Drives) |
|
RAID Controller & Support |
No |
|
Display ports |
2 x DisplayPort™, 1 x VGA |
|
Network interface |
2 x 1 GbE (RJ45) |
|
Available PCIe slots |
1 x Half Height PCIe x16 Gen 3 |
|
Archiving to external NAS |
Yes, through LAN port |
|
Credential and Key encryption |
Trusted Platform Module (TPM) 2.0 |
|
Redundant Power Supply |
No |
|
Remote management |
No |
|
General information |
|
|
Hardware warranty |
5 years full system warranty (incl. HDD) Onsite support next business day (additional conditions may apply, see detailed datasheet) |
|
Dimensions |
290 x 92.6 x 292 (mm) 11.42” x 3.7 x 11.50” |
|
Weight |
5.26 kg (min) 11.57 lbs. (min) |
|
Power input |
100~240V, 50/60 Hz |
|
Max. power consumption |
300W up to 90% efficiency (80 Plus Gold) |
|
BTU Rating |
1,024 BTU/h (max. theoretical) |
|
Protection |
OVP (over voltage), OCP (over current), OTP (over temp), SCP (short circuit) |
|
Environmental (This unit is intended for stationary server room and office use, according to the conditions stated below.) |
|
|
Operating temperature |
5⁰ - 45⁰ C / 41⁰ - 113⁰ F |
|
Storage temperature |
-40⁰ - 65⁰ C / -40⁰ - 149⁰ F |
|
Humidity |
20 – 80% relative humidity (non-condensing) |
|
Regulatory |
|
|
Safety & emission standards |
CE (class A), UKCA, FCC, RCM, UL, Mexico (NOM), VCCI |
|
Trade compliance |
NDAA Compliant |
